Palfinger PK19 on Isuzu FTS800 4x4 Lines Crane Truck

This lines crane truck has been designed specifically for off road applications. The Isuzu FTS800 4x4 is robust and reliable, and the Alison Auto Transmission is easy to use and gets the power to the ground effectively. The added benefit of a low range box and rear diff locks means this truck is well equipped to get into those hard to access locations.

Manoeuvrability + traction + functional build = Productivity & Utilisation

The Palfinger PK19 crane has all the power required to handle the common distribution poles and HPSC is fitted as a standard safety feature, which electronically limits the lift zone depending on where the stabilisers are placed. The design includes a very ridged subframe providing torsional stability to allow the crane to operate at maximum performance. The remote radio controller is designed specifically for the lines application providing auger and tamper controls. The hydraulic hoses are internally routed to the boom tip, and the truck is set up with auxiliary functions for pole puller and tamper via a retractable hose reel at the rear.

DESIGNED for the Kiwi linesman...

Clear deck with certified pop-up tie points and easy access steps
Double opening toolbox behind cab for storing long items
Outrigger pads and wheel chocks in dedicated compartments on each side
Safety grip tread on deck
Safety yellow on handles and steps
Full width storage container at the rear for hydraulic tamper
Retractable twin hose reel at rear for tamper or pole puller
LED flashing beacon lights front and rear
LED work lights mounted front and rear
Optional removable auger holder on deck

Let's Talk

Reach out today to Kingsley our Specialist Vehicle Consultant for pricing and availability

Enquire Now

SKU: BT7-8 Categories: Not Clickable, Crane Trucks, General, Industry, Line Crane Trucks, Power Energy, Products

Specifications

Description

Additional information

Model	PK19.001 SLD5 B
Size T/M	17.8
Specification/Type	Knuckle boom
Max Lift	4300kg
Distance at Max Lift	4.10m
Maximum Hydraulic Reach	10.3m
Weight at Max Reach	1600kg
Max Reach	10.3m
Manual Extension	S
HPSC Outrigger Mgt. System	S
Stabiliser Spread	6,600
Radio Controlled	S
Auger Function	S
Operating pressure (PSI)	360
Operating Flow (LPM)	45-65
Vehicle Manufacturer	Isuzu
Vehicle Model	FTS800
Specifications	4x4
HP	260
Transmission	Allison Auto
Difflocker/Traction Control	Standard
